Wacker Neuson RD27 Double Drum Roller
Information
Additional information
| Make | |
|---|---|
| Model | RD27 |
| Weight | 2.7 t |
Equipment Overview
The Wacker Neuson RD27 is a tandem double drum roller with a 1,200 mm drum width, built for asphalt compaction with a three-point articulated pendulum joint that keeps weight evenly distributed across both drums. It has an operating weight of around 2,690 kg, suited to compact and confined construction sites where manoeuvrability matters.
Power comes from a Kubota D1503 diesel engine producing 23.5 kW, driving all wheels through an articulated-frame steering system. The drums vibrate at up to 67 Hz, and hydraulic traction control (Automatic Slip Control) keeps the wheels from spinning for good gradeability and stability on slopes. The compact design gives the operator a clear view of the drums for precise, close-quarters compaction.
Technical Specifications
| Specification | Value |
|---|---|
| Engine | Kubota D1503 |
| Power Output | 23.5 kW |
| Max Torque | NA |
| Emission Standard | NA |
| Transmission | Hydrostatic |
| Drive Type | All-wheel drive, articulated-frame steering |
| Operating Weight | 2,690 kg |
| Compaction Width | 1,200 mm |
Dimensions
| Dimension | Value |
|---|---|
| Length | 2,460 mm |
| Width | 1,310 mm |
| Height | 2,390 mm |
| Wheelbase | NA |
| Turning Radius | 2,370 mm (outside) |
Typical Applications
- Confined and compact construction sites
- Car park and driveway asphalt compaction
- Municipal road repair and patching
- Compaction on sloped or uneven terrain
