CAT CS433E Smooth Drum Roller
Information
Additional information
| Make | |
|---|---|
| Model | CS433E |
| Weight | 7.4 t |
Equipment Overview
The Caterpillar CS433E is a smooth drum vibratory soil compactor with a 1,676 mm drum width, part of the 400E-Series soil compactors known for productivity, comfort and serviceability. It has an operating weight of 7,390 kg, providing exceptional performance on flat or aggressive terrain, ideal for site preparation, sub-base compaction and water and sewer trench work.
Power comes from a Caterpillar 3054C turbocharged engine producing 100 hp (75 kW), meeting EU Stage II emissions and maintaining power at high altitudes. The exclusive dual pump propel system provides separate balanced hydraulic flow to the rear drive axle and front drum drive motor for unmatched gradeability and reduced spin-out in low-traction conditions. The vibratory system runs at 31.9 Hz with up to 134 kN of centrifugal force, and an optional two-piece padfoot conversion kit expands the application range to cohesive or semi-cohesive materials.
Technical Specifications
| Specification | Value |
|---|---|
| Engine | Caterpillar 3054C, turbocharged diesel |
| Power Output | 100 hp (75 kW) |
| Max Torque | NA |
| Emission Standard | EU Stage II |
| Transmission | Hydrostatic |
| Drive Type | Dual pump propel: drum drive and rear axle |
| Operating Weight | 7,390 kg |
| Drum Width | 1,676 mm |
| Exciter Frequency | 31.9 Hz |
| Centrifugal Force | Up to 134 kN |
Dimensions
| Dimension | Value |
|---|---|
| Length | 4,963 mm |
| Width | 1,652 mm |
| Height | 2,972 mm |
| Wheelbase | 2,603 mm |
| Turning Radius | NA |
Typical Applications
- Site preparation and sub-base compaction
- Water and sewer trench work
- Road and residential construction
- Cohesive soil compaction with the optional padfoot conversion kit
