EquipmentWacker Neuson ST11 Posi-Track Loader
Model
ST11
Wacker Neuson ST11 Posi-Track Loader
Information
Additional information
| Make | |
|---|---|
| Model | ST11 |
| Weight | 2.2 t |
| Capacity | 0.4 t |
| Power | 41 hp |
Equipment Overview
The Wacker Neuson ST11 is a compact track loader built for landscaping and light site work, the first compact-frame tracked loader in Wacker Neuson’s ST range. It delivers 41 hp from a Kubota diesel engine and a 400 kg rated operating capacity, suited to tight construction sites needing a narrow 1,250 mm-wide frame with plenty of pushing power.
Power comes from a Kubota V1505T turbocharged diesel engine driving a radial-lift boom through a 2-speed hydrostatic transmission, with a top speed of 10 km/h. A 39 L/min standard auxiliary hydraulic circuit powers attachments such as augers and asphalt cutters, and a floating valve equalises the bucket to ground level for levelling work.
Technical Specifications
| Specification | Value |
|---|---|
| Engine | Kubota V1505T, turbo diesel, 1.5 L |
| Power Output | 41 hp (30.5 kW ISO) |
| Max Torque | NA |
| Emission Standard | NA |
| Drive Type | 2-speed hydrostatic track drive |
| Operating Weight | 2,200 kg |
| Rated Operating Capacity (35%) | 400 kg |
| Tipping Load | 1,040 kg (derived from 50% ROC of 520 kg) |
| Auxiliary Hydraulic Flow | 39 L/min (180 bar) |
| Max Travel Speed | 4.5 km/h low (10.0 km/h high) |
Dimensions
| Dimension | Value |
|---|---|
| Length | 2,905 mm (with bucket) |
| Width | 1,250 mm |
| Height | 1,950 mm (top of ROPS) |
| Wheelbase | 1,218 mm (track on ground) |
| Turning Radius | NA |
Typical Applications
- Landscaping and tight-access site work
- Grading and levelling
- Auguring and material handling
- Rental and contractor fleet general-purpose work
