EquipmentLiebherr LR614 Track Loader
Model
LR614
Liebherr LR614 Track Loader
Information
Additional information
| Make | |
|---|---|
| Model | LR614 |
| Weight | 11 t |
| Bucket | 1.4 m3 |
Equipment Overview
The Liebherr LR614 is a crawler loader built for material handling, digging, and dozing work, a smaller, discontinued model in Liebherr’s crawler loader range that has been superseded by the current LR626. It delivers 97 hp of net power and an 11,180 kg operating weight, suited to construction and earthmoving sites needing a compact track loader.
Power drives a hydrostatic travel system through independently controlled tracks, giving the operator precise steering including turning on the spot, characteristic of Liebherr’s crawler loader range. A 1.8 yd³ bucket and low ground pressure suit the LR614 to soft or uneven ground where wheeled loaders would struggle for traction.
Technical Specifications
| Specification | Value |
|---|---|
| Engine | NA |
| Power Output (net) | 97 hp |
| Max Torque | NA |
| Emission Standard | NA |
| Drive Type | Hydrostatic track drive |
| Operating Weight | 11,180 kg |
| Bucket Capacity | 1.38 m³ (1.8 yd³, struck) |
| Ground Pressure | 54.9 kPa (7.96 psi) |
| Max Travel Speed | 9.5 km/h |
Dimensions
| Dimension | Value |
|---|---|
| Length | 5,703 mm (with bucket on ground) |
| Width | 2,057 mm (outside of tracks) |
| Height | 3,000 mm (to top of cab) |
| Wheelbase | 2,176 mm (track on ground) |
| Turning Radius | NA |
Typical Applications
- Material handling on soft or uneven ground
- General construction and earthmoving
- Site work needing a compact track loader
- Loading and material transport
