Hyundai R250 Medium Excavator
Information
Additional information
| Make | |
|---|---|
| Model | R250 |
| Weight | 25 t |
Equipment Overview
The Hyundai R250 is a 25.2-tonne excavator built for general construction, utility work and civil earthmoving where a step up in size and lifting power from the 22-tonne class is needed. A long undercarriage adds stability during digging and lifting, and the machine carries a bucket capacity of 1.08 m³ standard, giving it a useful balance of digging force and loading volume for day-to-day site work.
Bucket digging force reaches around 157 kN, with a maximum digging depth of 7 m and a maximum reach of 10.19 m putting the machine’s working envelope well ahead of smaller 20-tonne class excavators. As with other Hyundai excavators in this range, the machine is built with ROPS cabin protection, a standard boom and bucket configuration, and an overload alert system for safer lifting work.
Technical Specifications
| Specification | Value |
|---|---|
| Engine | NA |
| Power Output | NA |
| Max Torque | NA |
| Emission Standard | NA |
| Transmission | Hydrostatic, 2-speed travel |
| Drive Type | Steel track, 600 mm shoes |
| Operating Weight | 25,200 kg |
| Digging Depth | 7,000 mm |
| Bucket Capacity | 1.08 m³ |
| Reach | 10,190 mm |
Dimensions
| Dimension | Value |
|---|---|
| Length | 9,920 mm |
| Width | 3,180 mm |
| Height | 3,220 mm |
| Track Width | 600 mm |
| Tail Swing Radius | NA |
Typical Applications
- General construction and civil earthworks
- Utility installation and trenching
- Truck loading and material handling
- Deep excavation and foundation work
